Material Recommendation
OEM Refrigerant Compressors - Material Recommendations

The Complete contaniment of refrigerants and oil is crucial to the long-term operation of hermetic and semi-hermetic refrigerant compressors, and Interface Solution, Inc. recommends only the highest performing gasket meterials for these applications.
To meet this need, we offer a selection of gasket meterials that produce exceptional sealing capabilities at low flange pressures.
Our MP-15 and CMP-4000 products are ideally suited for semi-hermetic compressor applications, including chilers, screw compressors and reciprocating compressors.

Compressor	Value Grade
Hermetic Applications	N-8092CT
Semi-Hermetic Application	CMP-4000 MP-15

Because hermetic compressors requires homogenous, conformal metarial of precise thickness, Interface Solution, Inc. manufactures N-8092CT in many close tolerance thickness to meet the stringent requirements of hermetic compressor manufactuers around the world. In addition, we highly recommend N-8092CT for use in hermetic refrigeration compressors applications such ad refrigerators, freezers and small air conditioning units. For comparison purpose, typicaly performance values appear above.

Gasket Materials	Density(gm/cc)	Bider Type	Maximum Intermittent Temperature(℃)	Recommended Fluids to Seal	Minimum Tensile Strenth AMD(MPa)	Compressor Type
MP-15	1.54	Chloroprene(CR)	205	Refrigerant, Oil	10.34	Semi-Hermetic
CMP-4000	1.60	NBR	350	Refrigerant, Oil	23.00	Semi-Hermetic
N-8092CT	1.20	NBR	180	Refrigerant, Oil	11.03	Hermetic
